HDC-9100N/PF
Digital Chart
Digital chart that provides accurate vision tests with various charts and eye charts
- Supports precise vision tests
- High-definition LCD charts
- Adjustable eye examination distances
MENU
Explore Details
Supports precise vision tests
The 100 various charts support all kinds of examinations for visual acuity and visual function measurements. Provide the various such as English, Numeral, Landolt C, Snellen E, Children chart other charts. Not only phoria tests are available to measure but also all visual acuity tests are also able to measure such as binocular balance test and stereoscopic vision test.








High-definition LCD charts
24’’ Color TFT-LCD Polarized Panel provides a high resolution chart of 1920 x 1080 pixels. This High Resolution LCD provides a broad test range from 0.03 to 2.0 chart without distortion.
Adjustable eye examination distances
Working distance can be adjusted in any testing environments for user convenience. *1.5 m ~ 6 m (0.1 m unit)
Huvitz MEMBERS
If you want more ophthalmology & optometry content
join Huvitz Members
Specifications
1. LCD Type
N-Type (Non- Polarized Panel) : 24 inch Full HD TFT LCD
PF-Type (Polarized Panel) : 24 inch Full HD TFT LCD
2. Hardware Specification
Resolution
1920x1080 pixels
White Luminance
250 cd/m²
Chart Window Size
24 inch, 531.4 mm (H) x 298.9 mm (V)
Adapter Power Consumption
100-250 V~, 1.5-0.75 A, 50-60 Hz
Model: MDS-060AAS12BM
Product Power Consumption
12V DC, 4A
Main Body Size / Weight
568 mm (W) x 336 mm (H) x 80 mm (D) / 6.1 kg
Remote Control Size / Weight
64 mm (W) x 195 mm (H) x 21 mm (D) / 160 g
Test Distance
1.5 m ~ 6 m (0.1 m Step)
External Input
USB (Memory stick), CAN
Controls
Wired (CAN): HDR-7000, HDR-9000, CDR-3100
Wireless (IR) – Remote Control / HDR-7000 / HDR-9000
WiFi (IEEE802.11b 2.4GHz) – Remote Control / HDR-9000
Bluetooth 3.0
Main Body Fixing Method
Wall Mount
3. Optional
Optional
Red/Green Glasses
Polarization Glasses
4. Chart Function
Chart
Landolt Ring, Alphabet, Number, Tumbling E
Figures for Children, Russian Letter, Hiragana
Functional Chart (Red/Green, Cross Cylinder, Binocular Balance, Fusion Suppression,Phoria, Aniseikonia, Streopsis etc.)
Masking Filter
Dot, Row, Column
Red/Green Filter
Setting
Change IR Channel of Remote Controller (10 Channel)
Mode for Movie or Photo
Sleep Mode
Contrast Rearrange
Red/Green Balance
Color Adjustment for Red/Green Filter
Random Function
Chart Space Adjustment
Chart Background Switching
Test
Color Vision Test
HUE Test
Contrast Sensitivity Test
Etc.
Vergence, Saccadic, Stereopsis Training
Custom Program (2 Program Support)
4. Chart Function
Chart
Landolt Ring, Alphabet, Number, Tumbling E
Figures for Children, Russian Letter, Hiragana
Functional Chart (Red/Green, Cross Cylinder, Binocular Balance, Fusion Suppression,Phoria, Aniseikonia, Streopsis etc.)
Masking Filter
Dot, Row, Column
Red/Green Filter
Setting
Change IR Channel of Remote Controller (10 Channel)
Mode for Movie or Photo
Sleep Mode
Contrast Rearrange
Red/Green Balance
Color Adjustment for Red/Green Filter
Random Function
Chart Space Adjustment
Chart Background Switching
Test
Color Vision Test
HUE Test
Contrast Sensitivity Test
Etc.
Vergence, Saccadic, Stereopsis Training
Custom Program (2 Program Support)
* Specification and design are subject to change without notice.
FAQ
Q. What are the key features of the HDC-9100N/PF?
A. The HDC-9100N/PF is a digital chart that supports accurate visual acuity testing by providing more than 100 types of charts and optotypes. Its high-resolution LCD screen delivers clear and sharp images, and the examination distance can be freely adjusted to suit different clinical environments, allowing flexible use across various examination rooms.
Q. What types of vision charts are provided by the HDC-9100N/PF?
A. The HDC-9100N/PF offers over 100 different charts and optotypes, supporting all types of visual acuity and visual function examinations. These include polarized charts for binocular vision, stereopsis, and heterophoria/strabismus testing; ETDRS charts that account for convergence changes based on optotype size; and 12 types of color vision charts for color vision deficiency assessment, enabling accurate testing in diverse clinical settings.
Q. How can the visual acuity test distance be adjusted when using the HDC-9100N/PF?
A. HDC-9100N/PF는 검사 환경에 따라 시력 검사 거리를 자유롭게 조절할 수 있도록 설계된 디지털 차트입니다. 사용자 편의에 맞춰 1.5m부터 6m까지, 0.1m 단위로 세밀하게 거리 설정이 가능해 다양한 진료실 구조에서도 정확한 검사가 가능합니다.
Q. Can the HDC-9100N/PF be integrated with other devices?
A. Yes. The HDC-9100N/PF can be integrated with Huvitz digital refractors such as the HDR-9000 and HDR-7100P. This allows simultaneous control of both the refractor and the chart from the refractor’s control panel, streamlining examination flow and creating a more efficient optometry environment.
Q. From a user perspective, what are the advantages of the HDC-9100N/PF?
A. The HDC-9100N/PF enables a wide range of visual function tests to be easily performed on a single device by providing various polarized and functional charts. It supports binocular vision, stereopsis, heterophoria/strabismus, binocular balance, fusion suppression, and aniseikonia testing, as well as special lens-based tests such as cross-cylinder and red-green tests, significantly improving examination efficiency and accuracy.
